SKU:9007C54N2
Square D 9007C54N2 Heavy Duty NEMA Limit Switch, 1NO/1NC
Square D 9007C54N2 Heavy Duty NEMA Limit Switch, 1NO/1NC
3 in stock
Couldn't load pickup availability
Trusted & Secure Payments
Trusted & Secure Payments
Shop with confidence! Your transactions are protected with industry-standard encryption for a safe and secure checkout experience.
Free GTA Shipping on Orders Over $250
Free GTA Shipping on Orders Over $250
30-Day Return Policy
30-Day Return Policy
Thank you for shopping with us! We want you to be completely satisfied with your purchase. If you need to return a product, please review the following guidelines and instructions.
1) Return Window
You may request a return within 30 days of receiving your item.
2) Eligibility
To be eligible, items must be:
New, unused, and uninstalled, in the original packaging with all tags, accessories, manuals, and parts.
In resaleable condition (no markings, labels, writing, or damage to product or packaging).
Accompanied by a receipt or proof of purchase.
Note: Installed/energized electrical products are not returnable. This includes items that have been wired, powered, mounted, cut, crimped, soldered, or modified.
3) Start a Return (RMA Required)
Email info@greenbirdes.com with your order number, item(s), and reason for return.
We’ll review and, if eligible, issue an approval with instructions.
Do not ship items back without an approval — packages without an approval or RMA may be refused.
Unless the return is due to our error (wrong item, DOA/defective, or shipping damage reported on time), return shipping is the customer’s responsibility.
4) Damages, Defects & Shortages
Inspect your order upon delivery. Report shipping damage, defects, or shortages within 48 hours of receipt to info@greenbirdes.com. We will no longer be responsible for claims after this time.
Keep all packaging and take clear photos of the box, packing materials, labels, and the product.
We may coordinate a carrier inspection and provide next steps.
We’ll repair, replace, or refund at our discretion once the claim is validated and the item is returned per instructions.
5) Non-Returnable / Final-Sale Items
Breakers, fuses, and special-order items (including items we do not normally stock, factory builds, and vendor-direct shipments).
Cut-to-length or customized products (e.g., wire/cable cuts, tape/COB light cuts, custom assemblies, made-to-order finishes).
Opened consumables (bulbs/lamps, chemicals, adhesives) and batteries once installed/activated.
Any item installed, modified, or not in original packaging.
If a non-returnable item arrives damaged/defective, report it within the timeframe above so we can assist under the manufacturer or shipping claim process.
6) Restocking Fees
We do not generally charge restocking fees for online returns. However, we reserve the right to apply a 25-50% restocking fee in certain situations:
A return is requested on orders that have already been shipped out or delivered.
The product packaging has been opened or handling is required to restore the item to resaleable condition.
Special-order/vendor-direct items (if permitted by the vendor) may carry a vendor restocking fee of 50% plus any vendor return freight.
All fees are deducted from the refund.
7) Shipping Costs
Outbound shipping is non-refundable.
If your order qualified for “free shipping,” we may deduct our actual outbound shipping cost from the refund.
Return shipping is customer-paid unless the return is due to our error.
8) Exchanges
For the fastest turnaround, return the original item (once approved) and place a new order. We’ll process the return per this policy.
9) Refunds
After the return is received and inspected, we’ll email you the approval status.
Approved refunds are issued to the original payment method within 10 business days.
Your bank or card issuer may require additional time to post the credit.
If more than 15 business days have passed since approval, contact info@greenbirdes.com.
10) Warranties
Many products are covered by a manufacturer’s warranty. If a defect arises after installation/use, contact us with details and proof of purchase; we’ll help initiate a warranty claim per the manufacturer’s terms.
11) Incorrect Address / Refused Delivery
Shipments returned due to incorrect/undeliverable addresses or refused delivery may incur reshipping charges and/or restocking fees.
Green Bird Electric Solutions Inc.
39 Cranfield Rd, East York, ON M4B 1Z1 • +1 (416) 425-7863 • info@greenbirdes.com
Product Description
The Square D 9007C54N2 Heavy Duty NEMA Limit Switch is a robust, high-performance device designed to meet demanding industrial applications. This full-size limit switch features a light-torque rotary head for precise operation, suitable for both clockwise (CW) and counterclockwise (CCW) movement. Built with a durable zinc body and compliant with multiple NEMA ratings, this switch is engineered to deliver reliable performance even in harsh environments.
Key Features and Benefits:
- Heavy Duty Design: Ideal for rugged industrial applications.
- Rotary Head Actuator: Light-torque rotary head without lever for versatile movement.
- Dual Operation: CW and CCW movement for enhanced flexibility.
- Wide Voltage and Amperage Range: Supports up to 600V AC/DC and 10A.
- Durable Construction: Zinc body with IP67 rating for water and dust resistance.
- Extensive Environmental Compatibility: Operates in temperatures from -20°F to 185°F.
Specifications
Feature | Details |
---|---|
Item | Heavy Duty Limit Switch |
Actuator Location | Side |
Actuator Style | Rotary Head, No Lever |
Amps | 10 |
Body Material | Zinc |
Contact Form | 1NO/1NC |
Depth | 1.79" |
Electrical Connection | Screw Terminals |
Height | 4.02" |
IP Rating | IP67 |
Movement | CW/CCW, Low Torque |
NEMA Rating | 1, 2, 4, 6, 6P, 12, 13 |
Operating Force | 1.56 in.-lb. |
Operating Temperature Range | -20°F to 185°F |
Travel | 90° |
Voltage Rating | 600V AC/DC |
Width | 1.55" |
Wiring Entry | 1/2"-14 NPT Conduit |
