Siemens

SKU:

SE221

SE221

Regular price $105.60 CAD
Regular price Sale price $105.60 CAD
Sale Sold out

Siemens SE221 Fusible Light Duty Safety Switch, 240 VAC, 30 A, Single Throw Contact, 2 Poles

  • General duty
  • Cover interlock
  • Tangential knockouts through 200 A for easy conduit lineup
  • Quick make, quick break operating mechanism that ensures positive operation
  • Provisions for T, R, J, H, and K class fuses (T and J 100 to 200 A)
  • Generous wiring gutters that meet or exceed CEC wire-bending space requirements
  • Visible blade, double break switching action
  • Informative door labeling which includes replacement parts list
  • Handle and cover padlocking provisions
  • Side hinged door that opens past 180 deg for easier wiring
  • A unique enclosure design that adds rigidity and strength, its rolled edge prevents cuts and scrapes to conductors and to installers hands
  • Indoor enclosure

Specifications
Type Fusible
Voltage Rating 240
Amperage Rating 30
Phase 1
Number of Poles 2
Short Circuit Current Rating 10
Contact Form Single Throw
Enclosure Type NEMA 1
Material Steel
